Comperssion LoadCell-CMR11
The CMR 11 is a high-performance compression load cell designed specifically for weighbridges and heavy-duty truck scales. Its well-proven rocker pin design ensures self-alignment and eliminates the need for corner adjustments, providing reliable and consistent weighing results even under challenging industrial conditions. The stainless-steel, hermetically sealed housing offers excellent protection against moisture, dust, and vibration, guaranteeing long-term stability and maintenance-free operation.


ORDER CODE
​
1. CMR11-20T-1MV-SS-16
Capacity 20T
Sensitivity 1mV/V
Stainless Steel
Cable Length 16 Meter
​
2. CMR11-30T-1MV-SS-16
Capacity 30T
Sensitivity 1mV/V
Stainless Steel
Cable Length 16 Meter
